B-LCDAD-RPI1
DSI to LCD adapter board
Data brief
Features
•
Up to two lanes of MIPI/DSI data and I2C
interface support
•
Extended various displays with standard DSI
interface on STM32 EVAL/DK board family
Description
The DSI to LCD adapter board (order code B-
LCDAD-RPI1) provides a flexible connector from
the microcontroller motherboard (Samtec High
speed connector QTH-030) to the standard LCD
connector (TE 1-1734248).
It can be used on STM32 Evaluation or Discovery
boards which supports DSI connector, to connect
DSI to LCD adapter board for LCD applications.
Backside
Front view
1. Pictures are not contractual
November 2016
DocID029198 Rev 2
1/3
www.st.com
For further information contact your local STMicroelectronics sales office.
Ordering information
B-LCDAD-RPI1
1
Ordering information
To order the B-LCDAD-RPI1 adapter board, refer to
Table 1:
Table 1. Ordering information
Order code
B-LCDAD-RPI1
Product
B-LCDAD-RPI1 adapter board
2
Revision history
Table 2. Document revision history
Date
27-May-2016
09-Nov-2016
Revision
1
2
Initial release.
Updated LCD description in
Features
and
Description.
Changes
2/3
DocID029198 Rev 2
B-LCDAD-RPI1
