JOG-00823
OKI
Electronics Components
OL3300N-02
FP-LD MODULE for STM-1 I-1, S-1.1 STM-4 I-4(OC-3 IR-1, SR OC-12)
Rev. 1 [03. 2001]
1. DESCRIPTION
The OL3300N-02 Gull Wing Lead type LD module is a 1.3µm, InGaAsP/InP laser diode coupled
to a single mode fiber with a pigtail. It is designed for STM-1 I-1, S-1.1 STM-4 I-4(OC-3 IR-1, SR
OC-12).
2. FEATURES
•
1310nm FP-LD
•
Gull Wing Lead Package
•
Pigtail type
3. APPLICATION
•
OC-3,STM-1,OC-12,STM4
4.OPTICAL AND ELECTRICAL CHARACTERISTICS
(Ta = -40 to 85°C, unless otherwise specified)
Parameter
Symbol
Test Conditions
Min. Typ.
Max.
Unit
Fiber Output Power
P0
CW
0.2
mW
Operation Current
Iop
CW
100
mA
CW, BOL
40
Threshold Current
Ith
mA
CW, EOL
1.5* Ith-BOL
P0=0.2mW,RMS
1270
1360
nm
Center Wavelength
λc
Ta=0 to 85°C
Spectral Width
∆λ
P0 = 0.2mW,RMS (σ)
7.7
nm
LD Forward Voltage
Vf
Pf = 0.2mW
1.5
V
Rise/Fall times
Tr/Tf
10-90%, P
peak
=
0.2mW
0.5
ns
Monitor Current
Im
Pf = 0.2mW(RT/SOL)
300
1000
µ
A
Tracking Error
TER
(RT to WCT)
-1.5
+1.5
dB
µ
A
Photodiode Dark Current
I
D
V
R
= 2.2V
1
Photodiode Capacitance
Ct
V
R
=2.2V, f=1MHz
20
pF
Drawing No.: JOG-00823
OL3300N-02
Page 1 of 3
Oki Electric Industry Co., Ltd.
JOG-00823
OKI
Electronics Components
OL3300N-02
5.ABSOLUTE MAXIMUM RATING
Parameter
Fiber Output Power
LD Reverse Voltage
PD Forward Current
PD Reverse Current
PD Reverse Voltage
Operating Ambient Temperature (Ta)
Storage Temperature
Lead Soldering Temperature (10s)
Symbol
P0
V
R
I
F
I
R
V
R
Ta
Tstg
-
(Ta = 25°C, unless otherwise specified)
Rating
Unit
2
mW
2
V
50
mA
3
mA
15
V
°
C
-40 to 85
-40 to 85
°
C
260
°
C
6. CONNECTOR AND FIBER SPECIFICATIONS
Parameter
Fiber
Specifications
1.31
µ
m Single Mode Fiber
Code Diameter:0.9
Yellow
Bending Radius: 20 (min)
Heat-resistant
Length :1000 +/-50
SC-PC
Unit
-
mm
-
mm
-
mm
-
Connector
.
Drawing No.: JOG-00823
OL3300N-02
Page 2of 3
Oki Electric Industry Co., Ltd.
JOG-00823
OKI
Electronics Components
OL3300N-02
7.OUTLINE DRAWING
All dimensions in millimeters
Package No. (Unit: mm)
Copyright 2001 Oki Electric Industry Co., Ltd
.
Drawing No.: JOG-00823
OL3300N-02
Page 3of 3
Oki Electric Industry Co., Ltd.
