2018年08月19日 | 使用内部的MSI振荡器给STM32L476RG单片机提供80MHz的时钟

#include

#include

// 1<=nus<=13107

void delay_us(uint16_t nus)

{

if ((RCC->APB1ENR2 & RCC_APB1ENR2_LPTIM2EN) == 0)

{

RCC->APB1ENR2 |= RCC_APB1ENR2_LPTIM2EN;

LPTIM2->CFGR = 4 << LPTIM_CFGR_PRESC_Pos; // 80MHz/16=5MHz

LPTIM2->CR = LPTIM_CR_ENABLE;

}

LPTIM2->ARR = nus * 5 - 1;

LPTIM2->CR |= LPTIM_CR_SNGSTRT;

while ((LPTIM2->ISR & LPTIM_ISR_ARRM) == 0);

LPTIM2->ICR = LPTIM_ICR_ARRMCF;

}

int fputc(int ch, FILE *fp)

{

if (fp == stdout)

{

if (ch == '\n')

{

while ((USART2->ISR & USART_ISR_TXE) == 0);

USART2->TDR = '\r';

}

while ((USART2->ISR & USART_ISR_TXE) == 0);

USART2->TDR = ch;

}

return ch;

}

void set_clock(void)

{

RCC->APB1ENR1 |= RCC_APB1ENR1_PWREN;

PWR->CR1 |= PWR_CR1_DBP; // 允许访问备用区域寄存器

// 打开LSE

if ((RCC->BDCR & RCC_BDCR_LSEON) == 0)

{

RCC->BDCR |= RCC_BDCR_LSEON;

while ((RCC->BDCR & RCC_BDCR_LSERDY) == 0); // 等待LSE稳定

}

RCC->CR |= RCC_CR_MSIPLLEN; // MSI使用LSE校准MSI

// 配置PLL: MSI/M*N/R=4MHz/1*40/2=80MHz

RCC->PLLCFGR = RCC_PLLCFGR_PLLREN | (40 << RCC_PLLCFGR_PLLN_Pos) | RCC_PLLCFGR_PLLSRC_MSI;

RCC->CR |= RCC_CR_PLLON;

while ((RCC->CR & RCC_CR_PLLRDY) == 0); // 等待PLL稳定

// 根据参考手册3.3.3 Read access latency, Table 11. Number of wait states according to CPU clock (HCLK) frequency

// CPU时钟要达到64MHz以上, LATENCY必须为4WS

// 由PWR_CR1_VOS可知当前V_CORE为Range 1 (最高时钟频率80MHz)

FLASH->ACR |= FLASH_ACR_LATENCY_4WS; // 参阅: Increasing the CPU frequency

while ((FLASH->ACR & FLASH_ACR_LATENCY) != FLASH_ACR_LATENCY_4WS);

// 将PLL选作系统时钟

RCC->CFGR |= RCC_CFGR_SW;

while ((RCC->CFGR & RCC_CFGR_SWS) != RCC_CFGR_SWS);

// 刚开始MSI还没有校准, 所以使用115200波特率时必须要延时, 否则前四个字符会乱码

// 延时5个字节的时间, 每个字节69.4us, 共347us

delay_us(347);

// 使用9600波特率时, 发送一个字符就要833.3us, 远远大于这个时间, 所以无需延时

}

int main(void)

{

set_clock();

// LED灯配置

RCC->AHB2ENR |= RCC_AHB2ENR_GPIOAEN;

GPIOA->MODER &= ~GPIO_MODER_MODE5_1;

GPIOA->BSRR = GPIO_BSRR_BS5; // LED灯亮

// 配置串口2

RCC->APB1ENR1 |= RCC_APB1ENR1_USART2EN;

GPIOA->AFR[0] = 7 << GPIO_AFRL_AFSEL2_Pos;

GPIOA->MODER &= ~GPIO_MODER_MODE2_0;

//GPIOA->OSPEEDR |= GPIO_OSPEEDR_OSPEED2;

USART2->BRR = 80000000 / 115200; // 被除数为时钟频率, 除数为波特率

USART2->CR1 = USART_CR1_UE | USART_CR1_TE;

printf("ABCDEFGH\n");

printf("PWR->CR1=0x%08x\n", PWR->CR1);

printf("RCC->BDCR=0x%08x\n", RCC->BDCR);

printf("RCC->CFGR=0x%08x\n", RCC->CFGR);

printf("RCC->CR=0x%08x\n", RCC->CR);

printf("RCC->PLLCFGR=0x%08x\n", RCC->PLLCFGR);

printf("USART2->BRR=%d\n", USART2->BRR);

GPIOA->BRR = GPIO_BRR_BR5; // LED灯灭

while (1);

}

MSI晶振接到PLL上后会通过外部的LSE晶振进行自动校准。校准期间，不精准的MSI时钟频率被PLL放大之后就会显著地影响串口的时钟，导致串口字符乱码，因此时钟切换后串口发送第一个字符之前必须延时，等待MSI时钟校准。

解决串口乱码问题还有一个更简单的方法，无需延时。单片机内部还带有一个16MHz的HSI时钟，在RCC->CCIPR寄存器中将USART2的时钟由与MSI有关的APB1时钟切换到HSI时钟，就能彻底解决问题。

【程序2】

#include

#include

int fputc(int ch, FILE *fp)

{

if (fp == stdout)

{

if (ch == '\n')

{

while ((USART2->ISR & USART_ISR_TXE) == 0);

USART2->TDR = '\r';

}

while ((USART2->ISR & USART_ISR_TXE) == 0);

USART2->TDR = ch;

}

return ch;

}

void set_clock(void)

{

RCC->APB1ENR1 |= RCC_APB1ENR1_PWREN;

PWR->CR1 |= PWR_CR1_DBP; // 允许访问备用区域寄存器

// 打开LSE

if ((RCC->BDCR & RCC_BDCR_LSEON) == 0)

{

RCC->BDCR |= RCC_BDCR_LSEON;

while ((RCC->BDCR & RCC_BDCR_LSERDY) == 0); // 等待LSE稳定

}

RCC->CR |= RCC_CR_MSIPLLEN; // MSI使用LSE校准MSI

// 配置PLL: MSI/M*N/R=4MHz/1*40/2=80MHz

RCC->PLLCFGR = RCC_PLLCFGR_PLLREN | (40 << RCC_PLLCFGR_PLLN_Pos) | RCC_PLLCFGR_PLLSRC_MSI;

RCC->CR |= RCC_CR_PLLON;

while ((RCC->CR & RCC_CR_PLLRDY) == 0); // 等待PLL稳定

// 根据参考手册3.3.3 Read access latency, Table 11. Number of wait states according to CPU clock (HCLK) frequency

// CPU时钟要达到64MHz以上, LATENCY必须为4WS

// 由PWR_CR1_VOS可知当前V_CORE为Range 1 (最高时钟频率80MHz)

FLASH->ACR |= FLASH_ACR_LATENCY_4WS; // 参阅: Increasing the CPU frequency

while ((FLASH->ACR & FLASH_ACR_LATENCY) != FLASH_ACR_LATENCY_4WS);

// 将PLL选作系统时钟

RCC->CFGR |= RCC_CFGR_SW;

while ((RCC->CFGR & RCC_CFGR_SWS) != RCC_CFGR_SWS);

}

int main(void)

{

set_clock();

// LED灯配置

RCC->AHB2ENR |= RCC_AHB2ENR_GPIOAEN;

GPIOA->MODER &= ~GPIO_MODER_MODE5_1;

GPIOA->BSRR = GPIO_BSRR_BS5; // LED灯亮

// 配置串口2

RCC->APB1ENR1 |= RCC_APB1ENR1_USART2EN;

GPIOA->AFR[0] = 7 << GPIO_AFRL_AFSEL2_Pos;

GPIOA->MODER &= ~GPIO_MODER_MODE2_0;

//GPIOA->OSPEEDR |= GPIO_OSPEEDR_OSPEED2;

// 使用HSI16作为USART2的时钟可以避免乱码

RCC->CR |= RCC_CR_HSION;

while ((RCC->CR & RCC_CR_HSIRDY) == 0);

RCC->CCIPR = RCC_CCIPR_USART2SEL_1; // HSI16作为USART2的时钟

USART2->BRR = 16000000 / 115200; // 被除数为时钟频率, 除数为波特率

USART2->CR1 = USART_CR1_UE | USART_CR1_TE;

printf("ABCDEFGH\n");

printf("PWR->CR1=0x%08x\n", PWR->CR1);

printf("RCC->BDCR=0x%08x\n", RCC->BDCR);

printf("RCC->CFGR=0x%08x\n", RCC->CFGR);

printf("RCC->CR=0x%08x\n", RCC->CR);

printf("RCC->PLLCFGR=0x%08x\n", RCC->PLLCFGR);

printf("USART2->BRR=%d\n", USART2->BRR);

GPIOA->BRR = GPIO_BRR_BR5; // LED灯灭

while (1);

}
