2019年08月05日 | system_stm32f10x.c（V3.5.0）解读

******************************************************************************

  * @file    system_stm32f10x.c

  * @author  MCD Application Team

  * @version V3.5.0

  * @date    11-March-2011

  * @brief   CMSIS Cortex-M3 Device Peripheral Access Layer System Source File.

  *

  * 1.  This file provides two functions and one global variable to be called from

  *     user application:

  *      - SystemInit(): Setups the system clock (System clock source, PLL Multiplier

  *                      factors, AHB/APBx prescalers and Flash settings).

  *                      This function is called at startup just after reset and

  *                      before branch to main program. This call is made inside

  *                      the "startup_stm32f10x_xx.s" file.

  *

  *      - SystemCoreClock variable: Contains the core clock (HCLK), it can be used

  *                                  by the user application to setup the SysTick

  *                                  timer or configure other parameters.

  *

  *      - SystemCoreClockUpdate(): Updates the variable SystemCoreClock and must

  *                                 be called whenever the core clock is changed

  *                                 during program execution.

  *

  * 2. After each device reset the HSI (8 MHz) is used as system clock source.

  *    Then SystemInit() function is called, in "startup_stm32f10x_xx.s" file, to

  *    configure the system clock before to branch to main program.

  *

  * 3. If the system clock source selected by user fails to startup, the SystemInit()

  *    function will do nothing and HSI still used as system clock source. User can

  *    add some code to deal with this issue inside the SetSysClock() function.

  *

  * 4. The default value of HSE crystal is set to 8 MHz (or 25 MHz, depedning on

  *    the product used), refer to "HSE_VALUE" define in "stm32f10x.h" file.

  *    When HSE is used as system clock source, directly or through PLL, and you

  *    are using different crystal you have to adapt the HSE value to your own

  *    configuration.

  *

  ******************************************************************************

由第2条可以得知，单片机一上电或复位，以8M的HSI运行，之后执行函数SystemInit ()，此函数的功能主要是复位与时钟相关的寄存器，并执行SetSysClock（）。

#if defined (STM32F10X_LD_VL) || (defined STM32F10X_MD_VL) || (defined STM32F10X_HD_VL)

/* #define SYSCLK_FREQ_HSE    HSE_VALUE */

 #define SYSCLK_FREQ_24MHz  24000000

#else

/* #define SYSCLK_FREQ_HSE    HSE_VALUE */

/* #define SYSCLK_FREQ_24MHz  24000000 */

/* #define SYSCLK_FREQ_36MHz  36000000 */

/* #define SYSCLK_FREQ_48MHz  48000000 */

/* #define SYSCLK_FREQ_56MHz  56000000 */

#define SYSCLK_FREQ_72MHz  72000000

#endif

由此部分代码可知，默认状态下，在函数SetSysClock（）中将会执行函数SetSysClockTo72()。

  if (HSEStatus == (uint32_t)0x01)

  {

    /* Enable Prefetch Buffer */

    FLASH->ACR |= FLASH_ACR_PRFTBE;

    /* Flash 2 wait state */

    FLASH->ACR &= (uint32_t)((uint32_t)~FLASH_ACR_LATENCY);

    FLASH->ACR |= (uint32_t)FLASH_ACR_LATENCY_2;

    /* HCLK = SYSCLK */

    RCC->CFGR |= (uint32_t)RCC_CFGR_HPRE_DIV1;

    /* PCLK2 = HCLK */

    RCC->CFGR |= (uint32_t)RCC_CFGR_PPRE2_DIV1;

    /* PCLK1 = HCLK */

    RCC->CFGR |= (uint32_t)RCC_CFGR_PPRE1_DIV2;

#ifdef STM32F10X_CL

    /* Configure PLLs ------------------------------------------------------*/

    /* PLL2 configuration: PLL2CLK = (HSE / 5) * 8 = 40 MHz */

    /* PREDIV1 configuration: PREDIV1CLK = PLL2 / 5 = 8 MHz */

    RCC->CFGR2 &= (uint32_t)~(RCC_CFGR2_PREDIV2 | RCC_CFGR2_PLL2MUL |

                              RCC_CFGR2_PREDIV1 | RCC_CFGR2_PREDIV1SRC);

    RCC->CFGR2 |= (uint32_t)(RCC_CFGR2_PREDIV2_DIV5 | RCC_CFGR2_PLL2MUL8 |

                             RCC_CFGR2_PREDIV1SRC_PLL2 | RCC_CFGR2_PREDIV1_DIV5);

    /* Enable PLL2 */

    RCC->CR |= RCC_CR_PLL2ON;

    /* Wait till PLL2 is ready */

    while((RCC->CR & RCC_CR_PLL2RDY) == 0)

    {

    }

    /* PLL configuration: PLLCLK = PREDIV1 * 9 = 72 MHz */

    RCC->CFGR &= (uint32_t)~(RCC_CFGR_PLLXTPRE | RCC_CFGR_PLLSRC | RCC_CFGR_PLLMULL);

    RCC->CFGR |= (uint32_t)(RCC_CFGR_PLLXTPRE_PREDIV1 | RCC_CFGR_PLLSRC_PREDIV1 |

                            RCC_CFGR_PLLMULL9);

#else

    /*  PLL configuration: PLLCLK = HSE * 9 = 72 MHz */

    RCC->CFGR &= (uint32_t)((uint32_t)~(RCC_CFGR_PLLSRC | RCC_CFGR_PLLXTPRE |

                                        RCC_CFGR_PLLMULL));

    RCC->CFGR |= (uint32_t)(RCC_CFGR_PLLSRC_HSE | RCC_CFGR_PLLMULL9);

#endif /* STM32F10X_CL */

    /* Enable PLL */

    RCC->CR |= RCC_CR_PLLON;

    /* Wait till PLL is ready */

    while((RCC->CR & RCC_CR_PLLRDY) == 0)

    {

    }

    /* Select PLL as system clock source */

    RCC->CFGR &= (uint32_t)((uint32_t)~(RCC_CFGR_SW));

    RCC->CFGR |= (uint32_t)RCC_CFGR_SW_PLL;

    /* Wait till PLL is used as system clock source */

    while ((RCC->CFGR & (uint32_t)RCC_CFGR_SWS) != (uint32_t)0x08)

    {

    }

  }

  else

  { /* If HSE fails to start-up, the application will have wrong clock

         configuration. User can add here some code to deal with this error */

  }

此部分代码说明当HSE准备好之后，就会配置PLL，使PLLCLK位72MHz，之后等待system clock source切换至PLL。

在实际的时钟配置中，在else处设置调试断点，可确认外部时钟是否起振工作。
