读写24LCxx系列的EEPROM的实例程序

;********************************************************
;*                    *
;*    ? PIC16F877A ?I2C Master 家Α???﹃?Α EEPROM ?絛ㄒ祘Α  *
;*                                                  *
;* Written by:  Richard Yang                                *
;*              Sr. Corporate Application Engineer            *
;*              MicroChip Technology Inc.                *
;* Date:        Oct. 2nd '2002                            *
;* Revision: 1.00                                    *
;********************************************************

;*************************************************
; This source code provides a demonstration of the MSSP peripheral
; on the PIC16F87x MCU.
;
;
;***********      The subroutines for EEPROM      *****************
;
; EE_Random_Read  ; EEPROM Random address Read from EEPROM
; EE_SEQU_Read  ; EEPROM Sequential Read form EEPROM
; EE_Ack_Check  ; Polling current status of EEPROM
; EE_Page_Write  ; Page Write function for EEPROM
; EE_Byte_Write  ; Write a byte to EEPROM with address setting
;
;***********      The subroutines for I2C      *****************
;
; Init_I2C_Master  ; Initial I2C Module for Master Mode , 7-bit address
; StartI2C  ; Send a START Condition !!
; StopI2C  ; Send s STOP Condition
; RstartI2C  ; Send a Repeat Start conditional to I2C
; Non_Ack  ; Send a Non-acknowLEDge signal to I2C
; An_Ack  ; Send a acknowledge signal to I2C
; Sebd_Byte  ; Send a byte to I2C bus
; RecI2C    ; Enable Read a byte form slave device
; I2C_Done  : Wait the I2C completed the currect process
;
;***************************************************

  list p=16f877a
  ＃i nclude

;
;***************************************
;      ﹚竡跑计?RAM???
;
  CBLOCK 0x20

  I2C_CTRl
  I2C_Addr
  I2C_Data
  I2C_Page_Length
  D_Count
  ENDC
  cblock 0x40
  I2C_Page_Buffer:8
  I2C_SEQU_Buffer:8
  endc
;
;***************************************
;      ﹚竡い耞?既?竟??

w_temp  EQU 0x72
status_temp EQU 0x73
pclath_temp EQU 0x74
;
;***************************************
;      ﹚竡 I2C ???の竲?
;
EEPROM_CMD equ 0xA0  ; Device adress of Slave Point
EE_Read  equ .1
EE_Write equ .0

;
#define  SCL PORTC,3  ; I2C SCL PIN
#define  SDA PORTC,4  ; I2C SDA pin

;

;********************************************
; Locates startup code @ the reset vector
;********************************************
Reset_Addr
  org  0x00
  nop
  goto Main_Init
;
  org  0x04
  goto ISR
;
;*************************************************************
;**** The Start Address of ISR is 0x004
;**** "PUSH" & "POP" ?ㄏノ絛ㄒ : 続ノ?钩 PIC16F877 ΤSHARE BANK ?PIC
;**************************************************************
ISR
Push  movwf  w_temp            ; save off current W register contents
  movf STATUS,w          ; move status register into W register
  movwf status_temp        ; save off contents of STATUS register
  movf PCLATH,W
  movwf pclath_temp
;
;        Put your interrupt code here
;
Pop  movf pclath_temp,W
  movwf PCLATH
  movf    status_temp,w    ; retrieve copy of STATUS register
  movwf STATUS            ; restore pre-isr STATUS register contents
  swapf  w_temp,f
  swapf  w_temp,w          ; restore pre-isr W register contents
;
  retfie                    ; return from interrupt


;----------------------------------------------------------------------

Main_Init
  pagesel Init_I2C_Master  ; Set PAGE to PCLATH Register
      call    Init_I2C_Master  ; Init the MSSP for I2C Master
;
      banksel I2C_Ctrl
  movlw EEPROM_CMD  ; Load EEPROM command address @ 0xA0
  movwf I2C_Ctrl
;
;
Main
;
;----------------------------------------------------------------------
;
;* ???代刚祘Α穦?盢?舱计?(0x40-0x47)糶??RMA0x40-0x47??竚
;* ?ノPage Write?よΑ盢8??じ舱?戈?糶? EEPROM ?
;* 秈︽?篈?盎代EEPROM琌??ЧΘ糶??笆??程?盢?糶
;* ??戈??Sequential Read?よΑ眖EEPROM弄?ㄓ??I2C_SEQU_Bufferい
;

Test_Page_RW
  movlw 0x08
  movwf I2C_Page_Length
  movlw I2C_Page_Buffer
_Fill_RAM movwf FSR
  movwf INDF
  incf FSR,W
  decfsz I2C_Page_Length,F
  goto _Fill_RAM
;
Test_Page_Write
;  banksel I2C_Ctrl
  movlw EEPROM_CMD  ; Load EEPROM command address @ 0xA0
  movwf I2C_Ctrl
  movlw 0x10    ; Select EEPROM location at 0x00
  movwf I2C_Addr
  movlw .8
  movwf I2C_Page_Length
  call EE_Page_Write
;
  call EE_Ack_Check
;
  banksel I2C_Ctrl
  movlw EEPROM_CMD  ; Load EEPROM command address @ 0xA0
  movwf I2C_Ctrl
  movlw 0x10
  movwf I2C_Addr
  movlw .8
  movwf I2C_Page_Length
  call EE_SEQU_Read
;
  goto $
;
;---------------------------------------------------------
;
;* ???代刚祘Α穦?糶????じ舱?戈?糶? EEPROM い
;* ?秈︽?篈?盎代琌??ЧΘ糶??笆??程?盢?糶
;* ??戈??眖EEPROM弄?ㄓ??I2C_Data既?竟い
;
Test_1byte_RW

   banksel I2C_CTRl
   movlw EEPROM_CMD   ; Load EEPROM command address @ 0xA0
   movwf I2C_Ctrl
   movlw 0x00    ; Select EEPROM LOCation at 0x00
   movwf I2C_Addr
   movlw 0xAA    ; Write data 0x5A to location 0x00 of EEPROM
   movwf I2C_Data
   call EE_Byte_Write
;
Test2  call EE_Ack_Check  ; Polling AcknowLEDge for next aCCess
;
   banksel I2C_Data
   movlw 0x00    ; Clear I2C data buffer
   movwf I2C_Data
;
Test3
   banksel I2C_Ctrl
   movlw EEPROM_CMD   ; Load EEPROM command address @ 0xA0
   movwf I2C_Ctrl
   movlw 0x00
   movwf I2C_Addr
   call EE_Random_Read
   ;
   goto  $
;

;
;******************************************************
;*           Random Read a Byte from EEPROM
;*
;* Input:
;*     - I2C_Ctrl : Control Byte of EEPROM
;*      - I2C_Addr : Location of EEPROM
;* Output:
;*      - I2C_Data : Read Data from EEPROM
;******************************************************
;
; Send Command for RANDOM READ :
; " Start+ 0xA0 + EE_Address + ReStart + 0xA1 + Read_Data + NAck + Stop "
;

EE_Random_Read
    call StartI2C  ; Set SSPCON2.SEN
;
   bcf  I2C_Ctrl,0  ; set for write Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
;
   movf I2C_Addr,W  ; Send out the Rendom address of EEPROM
   call Send_Byte
;
   call RstartI2C  ; Send a Repeat Start to I2C
;
   bsf  I2C_Ctrl,0  ; set for Read Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
;
   call RecI2C  ; Enable I2C Receive
;
   BANKSEL SSPBUF
   movf SSPBUF,W ; Save to I2C_Data First !!
   movwf I2C_Data

   call Non_Ack  ; Initial NACK Response !!

   call StopI2C  ; Initial STOP Condition
   return
;
;***************************************************************
;*                Sequential Read from EEPROM
;*
;* Input:
;*     - I2C_Ctrl : Control Byte of EEPROM
;*      - I2C_Addr : Start Location of EEPROM
;*     - I2C_Page_Length : How many byte need to read
;* Output:
;*      - I2C_SEQU_Buffer : Sequential Read Data buffer
;*
;***************************************************************
;
; Send Command for RANDOM READ :
; " Start+ 0xA0 + EE_Address + ReStart + 0xA1 + Read_Data + NAck + Stop "
;
EE_SEQU_Read
    call StartI2C  ; Set SSPCON2.SEN
;
   bcf  I2C_Ctrl,0  ; set for write Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
;
   movf I2C_Addr,W  ; Send out the Rendom address of EEPROM
   call Send_Byte
;
   call RstartI2C  ; Send a Repeat Start to I2C
;
   bsf  I2C_Ctrl,0  ; set for Read Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
;
   movlw I2C_SEQU_Buffer
   movwf FSR
;
_Sequ_Loop call RecI2C   ; Enable I2C Receive
   BANKSEL SSPBUF
   movf SSPBUF,W  ; Save to I2C_Data First !!
   movwf INDF
   incf FSR,F
   decfsz I2C_Page_Length,F
   goto _Cont_Read
   goto _End_Read
_Cont_Read call An_Ack
   goto _Sequ_Loop
;
_End_Read call Non_Ack   ; Initial NACK Response !!
   call StopI2C   ; Initial STOP Condition
   return
;
;******************************************************
;*              EEPROM Acknowledge Polling
;*
;*     --  The routine will polling the ACK
;*           response from EEPROM
;*    --  ACK=0 return
;*   --  ACK=1 send Restart & loop check
;*
;******************************************************
;
EE_Ack_Check
    call StartI2C  ; Set SSPCON2.SEN

   bcf  I2C_Ctrl,0  ; Clear for Write Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
_Ack_Polling
   BANKSEL SSPCON2
   btfss SSPCON2,ACKSTAT ; Check ACKSTAT bit , 0 = ACK , 1 = NACK
   goto ACK_Return  ; Ack = 0 ; EEPROM is Ready
_Ack_Hi        ; Ack = 1 ; EEPROM is Busy for Write
   call Delay_mS  ; Delay 500uS for next Ack polling
   call RstartI2C  ; Send a Repeat Start to I2C
   bcf  I2C_Ctrl,0  ; Clear for Write Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
   goto _Ack_Polling

ACK_Return
   call StopI2C   ; Initial STOP Condition
   return
;
;**********************************************************
;*           Page Write 1 to 8 Bytes to EEPROM
;*
;*  Input:
;*     - I2C_Ctrl : Control Byte of EEPROM
;*     - I2C_Addr : Location of EEPROM
;*   - I2C_Page_Buffer: RAM location of Data
;*     - I2C_Page_Length : Data length count
;*
;**********************************************************
;
; Send Command for PAGE WRITE :
; " Start+ 0xA0 + EE_Address + W_Data 0+ .. + W_Data N + Stop "
;
EE_Page_Write
   movf I2C_Page_Length,W
   btfsc STATUS,Z
   return
;
    call StartI2C  ; Set SSPCON2.SEN
;
   bcf  I2C_Ctrl,0  ; Clear for Write Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
;
   movf I2C_Addr,W  ; Send out the Command
   call Send_Byte
;
   movlw I2C_Page_Buffer
   movwf FSR
_W1   movf INDF,W
   call Send_Byte
   incf FSR,F
   decfsz I2C_Page_Length,F
   goto _W1
;
    call StopI2C   ; Initial STOP Condition
   return
;
;
;*******************************************************
;*               Write a Byte to EEPROM
;*
;* Input:
;*     - I2C_Ctrl : Control Byte of EEPROM
;*      - I2C_Addr : Location of EEPROM
;*      - I2C_Data : Data to EEPROM

;*
;*******************************************************
;
; Send Command for BYTE WRITE :
; " Start+ 0xA0 + EE_Address + Write_Data + Stop "
;
EE_Byte_Write
    call StartI2C  ; Set SSPCON2.SEN
;
   bcf  I2C_CTRl,0  ; Clear for Write Command
   movf I2C_Ctrl,W  ; Send Slave Address to I2C Bus
   call Send_Byte
;
   movf I2C_Addr,W  ; Send out the Command
   call Send_Byte
;
   movf I2C_Data,W  ; Send out the Data
   call Send_Byte
;
    call StopI2C   ; Initial STOP Condition
   return
;
;**********************************************************************
;
;   As following subroutines perform commonly used I2C functions.
;      You CAN use these subroutines for your I2C aCCess
;
;**********************************************************************
;
;*** Initial I2Cmodule fot 7-bit I2C Master Mode with 100Kcps @4MHz
;
Init_I2C_Master
   BANKSEL TRISC   ; Initial PortC,bit 3 & 4 as Input
    bsf  SCL    ; RC3 = SCL  ,  RC4 = SDA
   bsf  SDA
;
    BANKSEL PORTC
    bsf  SCL    ; SCL = Hi
    bsf  SDA    ; SDA = Hi
;
   movlw b'00101000'  ; I2C Master Mode, CLOCk Rate: FOSC/(4*SSPADD+1)
   movwf SSPCON   ;
;
         banksel SSPADD
         movlw   .9              ; This gives 100KHz I2C clock @ 4MHz
   movwf   SSPADD   ; (4MHz/4) / (9+1)= 100KHz
;
       movlw   b'10000000'     ; DISAble slew rate control,
         movwf   SSPSTAT   ; and clear status bits
;
          movlw   b'00000000'     ; Set SCL,SDA into Ready status
         movwf   SSPCON2
;
   return
;
;******   Send START condition to bus   *******
;
StartI2C    ; Initiate the I2C START condition.
         banksel SSPCON2
          bsf     SSPCON2,SEN
         goto I2C_Done
;
;******   Send STOP condition to bus   *******
;
StopI2C
        banksel SSPCON2
         bsf     SSPCON2,PEN
         goto I2C_Done
;
;******   Send RESTART condition to bus   *******
;
RstartI2C
         banksel SSPCON2
         bsf     SSPCON2,RSEN
         goto I2C_Done
;
;******   Send a Non-AcknowLEDge status to bus (ACK=1)    *******
;
Non_Ack
         banksel SSPCON2
         bsf     SSPCON2,ACKDT    ; Set the ACK bit
         bsf     SSPCON2,ACKEN    ; Initiate the NACK sequence.
         goto I2C_Done
;
;******   Send an Acknowledge status to bus (ACK=0)     *******
;
An_Ack
          banksel SSPCON2
         bcf     SSPCON2,ACKDT    ; Clear the ACK bit
         bsf     SSPCON2,ACKEN    ; Initiate the NACK sequence.
         goto I2C_Done
;
;******   Send data to I2C bus from Wreg.     *******
;
Send_Byte
   banksel SSPBUF
   movwf SSPBUF
   goto I2C_Done
;
;******   Enable I2C Receive for Master Mode     *******
;
RecI2C
        banksel SSPCON2
         bsf     SSPCON2,RCEN    ; Set the receive enable bit.
   goto I2C_Done
;
;******  Check the I2C stage is completed   ********
;
I2C_Done
         banksel PIR1
    btfss   PIR1,SSPIF ; Poll for SSPIF
         goto    $-1
         bcf     PIR1,SSPIF
         return
;
Delay_mS
   banksel D_Count
   movlw .124   ; Load .5mS Dealy Value
    movwf D_Count
_D_mS  nop
   decfsz D_Count,F
   goto _D_mS
   return
;
; *********** End Of Program !!!!!
;
   end
