2018年10月14日 | Tiny4412中断控制器(GIC)之外部中断

#include "regs.h"

void enable_mmu(unsigned long ttb);

void init_ttb(unsigned long *ttb_base);

void mmap(unsigned long *ttb_base, unsigned long va, unsigned long pa);

void memset(char *buf, char ch, int size);

void memcpy(char *dst, char *src, int size);

void do_irq(unsigned long regs[]);

void (*printf)(char *, ...) = 0x43e11434;

void main(void)

{

    unsigned long  vector_base = 0xffff0000;

    unsigned long  tt_base = 0x73000000;

    unsigned long *pdo_irq = 0x75000000;

    extern unsigned long vectors_start, vectors_end;

    memset(tt_base, 0x00, 16 * 1024);

    mmap(tt_base, vector_base, 0x70000000);

    enable_mmu(tt_base);

    memcpy(vector_base, vectors_start, 0x100);

    *pdo_irq = do_irq;

    //让cpu开中断，cpu可以接收中断，要关闭cpu的中断用cpsid

    //一条指令就可以完成对特殊功能寄存器的写操作，以前代码：

    //mrs r0,cpsr

    //bic r0,r0,#0x80  //清掉最高位

    //msr cpsr,r0

    __asm__ __volatile__ (

        "cpsie i\n"

    );

    //-------------------------------------------------------------------------

    // 使能GIC中断

    ICCICR_CPU0 = 1;

    ICCPMR_CPU0 =  0xff;  // Priority Unmask All Interrupt

    //------------ Eint26 for K1 irqID is 64-----------------

    ICDDCR = 1;

    // 64号中断优先级，the Zero is Highest priority

    // 该寄存器中每个中断号占8位，64号中断就在ICDIPTR16寄存器当中

    ICDIPR16_CPU0 = ~(0xff << 0);

    // 64号中断给哪个cpu发，该寄存器中每个中断号占8位，64号中断就在ICDIPTR16寄存器当中

    // 给cpu0发在ICDIPTR16_CPU0寄存器里面要写上，for CPU0, refer PG815

    // 如果给cpu1、cpu3两个发既要在ICDIPTR16_CPU0上写上也要在ICDIPTR16_CPU3上写入

    ICDIPTR16_CPU0 = (1 << 0);

    // enable interrupt 0，每个中断号占一位，64号中断在ICDISER2当中

    ICDISER2_CPU0 = (1 << 0);

    //-------------------------------------------------------------------------

    //使能外部中断控制器，设置中断引脚；内部中断不用这些设置(timer,watchdog中断等)

    GPX3CON  &= ~(0x7 << 8);

    GPX3CON  |=  (0xf << 8);  //Configure as Exint43_2 --- EINT26

    EXT_INT43CON  &=  ~(0x7 << 8);

    EXT_INT43CON  &=  ~(0x3 << 8); //设置触发边沿：rising edge

    EXT_INT43_MASK &= ~(0x1 << 2); //enable ExtINT43_2 --- EINT26 for K1

}

void do_irq(unsigned long regs[])

{

    if (EXT_INT43_PEND & (1 << 2)) {  //产看是不是发生中断

        printf("ExtInt43_2 \n");

        EXT_INT43_PEND |= (1 << 2);      //清除中断

    }

}

void enable_mmu(unsigned long ttb)

{

    unsigned long c1_flags;

    init_ttb(ttb);

    c1_flags = 1 | (1 << 3) | ( 1 << 11) | ( 1 << 13) |  (1 << 28);

    __asm__ __volatile__ (

        "mvn r0, #0 \n"

        "mcr p15, 0, r0, c3, c0, 0\n"

        "mcr p15, 0, %1, c2, c0, 0\n" //configure ttb

        "mrc p15, 0, r0, c1, c0, 0\n"

        "orr %0, r0, %0\n"

        "mcr p15, 0, %0, c1, c0, 0\n" //enable mmu

        :

        : "r" (c1_flags), "r" (ttb)

        : "r0"

    );

}

void init_ttb(unsigned long *ttb_base)

{

    unsigned long va, pa;

    for (va = 0x00000000; va < 0x10000000; va += 0x100000) { //Others

        pa = va;

        ttb_base[ va >> 20] = (pa & 0xfff00000) | 2;

    }

    for (va = 0x10000000; va < 0x14000000; va += 0x100000) { //SFR

        pa = va;

        ttb_base[ va >> 20] = (pa & 0xfff00000) |  2;

    }

    for (va = 0x40000000; va < 0x80000000; va += 0x100000) { //DRAM

        pa = va;

        ttb_base[ va >> 20] = (pa & 0xfff00000) | 2;

    }

}

void mmap(unsigned long *ttb_base, unsigned long va, unsigned long pa)

{

    ttb_base[ va >> 20] = (pa & 0xfff00000) |  2;

}

void memset(char *buf, char ch, int size)

{

    int i;

    for (i = 0; i < size; i ++)

        buf[i] = ch;

}

void memcpy(char *dst, char *src, int size)

{

    int i;

    for (i = 0; i < size; i ++)

        dst[i] = src[i];

}

__asm__ (

"vectors:\n"

    "b reset\n"

    "b und\n"

    "b swi\n"

    "b pre_abt\n"

    "b dat_abt\n"

    ".word 0\n"

    "b irq\n"

    "b fiq\n"

"reset:\n"

"und:\n"

    "mov sp, #0x74000000\n"

    "stmfd sp!, {r0-r12, lr}\n"

    "mov r0, sp\n"

    "mov r3, #0x74000000\n"

    "ldr r3, [r3]\n"

    "blx r3\n"

    "mov sp, #0x74000000\n"

    "ldmea sp, {r0-r12, pc}^\n"

"swi:\n"

"pre_abt:\n"

"dat_abt:\n"

"fiq:\n"

"irq:\n"

    "mov sp, #0x75000000\n"

    "sub lr, lr, #4    \n"

    "stmfd sp!, {r0-r12, lr}\n"

    "mov r0, sp\n"

    "mov r3, #0x75000000\n"

    "ldr r3, [r3]\n"

    "blx r3\n"

    "mov sp, #0x75000000\n"

    "ldmea sp, {r0-r12, pc}^\n"

"EOV:\n"

"vectors_start:\n"

    ".word vectors\n"

"vectors_end:\n"

    ".word EOV\n"

);

===================================================================

Makefile文件：

default:

    arm-linux-gcc -c test.c  -o test.o

    arm-linux-ld  -Ttext=0x70003000  test.o  -o test

    arm-linux-objcopy  -O binary  test  test.bin

clean:

    rm -f test.o  test  test.bin   *~

===============================================================
