Axial Lead and Cartridge Fuses
High-Reliability Subminiature
PICO
®
Fuse
Very Fast-Acting Fuse 265/266/267 Series
ELECTRICAL CHARACTERISTICS:
% of Ampere
Rating
100%
200%
Ampere
Rating
1/16 –15
1/16 –7
10
15
Opening
Time
4 hours,
Minimum
1 second,
Maximum
3 seconds,
Maximum
10 seconds,
Maximum
®
®
QPL
AGENCY APPROVALS:
Recognized under the Components Program
of Underwriters Laboratories and Certified by CSA.
AGENCY FILE NUMBERS:
UL E10480, CSA LR 29862.
FUSES TO MIL SPEC:
265 Series (except 1/16 ampere rating) is
available in FM08A on QPL for MIL-PRF-23419/8. To order, change 265
to 267.
265
000
Series
38.1
(1.50")
7.11
(.28")
3/4 A
38.1
(1.50")
2.36 (.093")
DIA.
INTERRUPTING RATINGS:
300 amperes at rated voltage VDC
50 amperes at rated voltage VAC
ENVIRONMENTAL SPECIFICATIONS:
Operating Temperature:
–55°C to 125°C.
Shock:
MIL-STD-202, Method 213, Test Condition I
(100 G’s peak for 6 milliseconds).
Transparent
Insulating Sleeve
266
000
Series
8.38 (.33) (Note 1)
7.11 (.28")
2.36 (.093")
DIA.
90°
3/4 A
Vibration:
MIL-STD-202, Method 201 (10–55 Hz);
MIL-STD-202, Method 204, Test Condition C (55–2000 Hz at 10 G’s Peak).
Salt Spray:
MIL-STD-202, Method 101, Test Condition B.
Seal Test:
MIL-STD-202, Method 112, Test Condition A.
Insulation Resistance (After Opening):
MIL-STD-202, Method
302, Test Condition A (1/2 Megohm minimum).
37.33
(1.47")
Transparent
Insulating Sleeve
(Note 1: 9.14 (.36") for 15 amp rating)
Thermal Shock:
MIL-STD-202, Method 107,
Test Condition B (–65°C to 125°C).
ORDERING INFORMATION:
Axial Lead
Catalog
Number
265.062
265.125
265.250
265.375
265.500
265.750
265
001
265
01.5
265
002
265
02.5
265
003
265
004
265
005
265
007
265
010
265
015
Radial Lead
Catalog
Number
266.062
266.125
266.250
266.375
266.500
266.750
266
001
266
01.5
266
002
266
02.5
266
003
266
004
266
005
266
007
266
010
266
015
Ampere
Rating
1/16
1/8
1/4
3/8
1/2
3/4
1
1
1
/
2
2
2
1
/
2
3
4
5
7
10
15
Voltage
Rating
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
32
Nominal
Resistance
Cold Ohms
7.0
2.1
0.71
0.42
0.28
0.17
0.125
0.08
0.055
0.042
0.03515
0.023
0.014
0.01
0.00645
0.004
Moisture Resistance:
MIL-STD-202, Method 106.
PHYSICAL SPECIFICATIONS:.
Materials:
Gold-Plated Copper Leads, Type II
Weight:
.32 Grams
Solderability:
MIL-STD-202, Method 208.
Lead Pull Force:
MIL-STD-202, Method 211,
Test Condition A (will withstand a 5 lb. axial pull test).
AQL (Electrical Characteristics):
Certified to 1% AQL.
Sampling:
Per MIL-STD-105, Inspection Level II.
Traceability and Identification Records:
Controlled by lot
number and retained on file for a minimum of three years. Copies of
Lot Certification Test data available when requested with order.
OPTIONS:
Special screening tests, burn-in, etc. can be supplied on
special order to meet specific requirements. For information on higher
current ratings, contact Littelfuse.
PATENTED
Please contact Littelfuse for Average Time Current Curve.
284
