COPAL ELECTRONICS
BRUSHLESS DC FANS
F412R
■
STANDARD SPECIFICATIONS
Item
Rated voltage
Voltage range
Rated current
Rotating speed
Air flow
Static pressure
Noise
Net weight
❈
: Figures in the table are typical values under rated operating condition.
F412R-12LLB
DC12 V
10.2 ~ 13.8 V
0.04 A
3750 min
-1
0.1 m
3
/min
12 Pa
14 dB (A)
4.5 ~ 5.7 V
0.08 A
4200 min
-1
0.11 m
3
/min
15 Pa
16 dB (A)
F412R-05LB
F412R-05MB
F412R-12LA
-12LB
F412R-12MA
-12MB
F412R-24LA
-24LB
F412R-24MA
-24MB
DC5 V
4.2 ~ 5.7 V
0.10 A
5400 min
-1
0.15 m
3
/min
26 Pa
23 dB (A)
DC12 V
10.2 ~ 13.8 V
0.04 A
4200 min
-1
0.11 m
3
/min
15 Pa
16 dB (A)
Approx. 20 g
10.2 ~ 13.8 V
0.06 A
5400 min
-1
0.15 m
3
/min
26 Pa
23 dB (A)
DC24 V
20.4 ~ 27.6 V
0.03 A
4200 min
-1
0.11 m
3
/min
15 Pa
16 dB (A)
20.4 ~ 26.4 V
0.04 A
5400 min
-1
0.15 m
3
/min
26 Pa
23 dB (A)
■
AIR FLOW PERFORMANCE CURVES
F412R-05LB
-12LA
-12LB
-24LA
-24LB
F412R-05MB
-12MA
-12MB
-24MA
-24MB
30
25
Static pressure (Pa)
20
15
10
5
F412R-12LLB
0
0.02
0.04
0.06
0.08
0.10
3
0.12
0.14
0.16
0.18
2.0
Air flow (m /min)
■
OUTLINE DIMENSIONS
300±20
Lead wire UL AWM 1007 AWG26
Red:
B
Rated voltage
Black: 0 V
4 –
φ
3.5
(Unit: mm)
Dimension of mounting hole for recommendation
φ
39
4 – C3
32±0.5
12.2±0.5
41±0.5
32±0.5
■
